- Plastic Snap Rivets (Large Head)
- For use where frequent insertions & extractions are required
- Removable/Re-usable Rivets
- Color: Black
- Packaging: 1000/bag
- Material: Nylon 6
- UL Rating: 94V-2
- UL File No. E41871
- RoHS Compliant
- Temp Range(Ref): -0 to 185 F (-40 to 85 C)
Unit of Measure
Mounting Hole Dia. |
N/A .122-.126 (3.1-3.2) inches (mm) |
Panel Thickness Range |
N/A .217-.256 (5.5-6.5) inches (mm) |
W1 |
N/A .118 (3) inches (mm) |
L1 |
N/A .315 (8) inches (mm) |
L2 |
N/A .32 (8) inches (mm) |
W2 |
N/A .394 (10) inches (mm) |
